Fuse link CH10x38 aM 12A/500V 002621008
Specifications
- ETI Code:
- 002621008
- Description:
- CH10x38 aM 12A/500V
- Class name:
- Fuse link
- efuse:
- 1
- Type:
- CH
- Size:
- CH10
- Rated current (A):
- 12
- Rated AC voltage (V):
- 500
- Characteristics:
- aM
- Breaking capacity AC (kA):
- 100
- Application:
- For relays, contactors and motors protection in case of short-circuit
- Dimensions:
- 10X38
- Power dissipation (W):
- 0,6
- Standards:
- IEC 60269-1, IEC 60269-2
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895906551
- Net weight of the product
- 7.6 g
- Customs tariff
- 85361050
- logis_net_width
- 10 mm
- logis_net_height
- 38 mm
- logis_net_depth
- 10 mm
Level 1 Packaging
- Basic packaging quantity
- 10
- EAN code for a basic packaging
- 3838895169482
- Basic packaging weight
- 0.08 kg
Level 2 Packaging
- Transport packaging quantity
- 500
- EAN code for a transport packaging
- 3838895169499
- Transport packaging weight
- 4.1 kg
- Pallet quantity
- 84000
ETIM Clasification
- Classification
- EC002704
- Class name
- Cylindrical fuse
- Size
- 10x38 mm
- Nominal current
- 12A
- Breaking capacity
- 100kA
Characteristic
