Fuse link CH10x38 aM 25A/400V 002621013

Specifications

ETI Code:
002621013
Description:
CH10x38 aM 25A/400V
Class name:
Fuse link
Type:
CH
Size:
CH10
Rated current (A):
25
Rated AC voltage (V):
400
Characteristics:
aM
Breaking capacity AC (kA):
100
Application:
For relays, contactors and motors protection in case of short-circuit
Dimensions:
10X38
Power dissipation (W):
1
Standards:
IEC 60269-1, IEC 60269-2

Documents

Product

EAN code for a single product
3838895581543
Net weight of the product
7.6 g
Customs tariff
85361050

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895169543
Basic packaging weight
0.08 kg
Basic packaging volume
0.042

Transport packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895169550
Transport packaging weight
4.1 kg
Transport packaging volume
3.386
Pallet quantity
84000
Pallet volume
568.848
Classification
EC002704
Class name
Cylindrical fuse
Breaking capacity
100kA
Nominal current
25A
Size
10x38 mm
ETIM Classification – Version 7.0

Images & Diagrams

Software & drivers

Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
002621013Fuse link, CH10x38 aM 25A/400VCCylindrical fuse-linksCHCH10aMaMFuse links D, D0, CC fuse linksCH10X38 AM 25A/4Rated current 25AType CHSize CH10Product group C low Voltage cylindrical fusesCharacteristics aMRated AC voltage 400VDimensions 10X38Breaking capacity AC 100kAPower dissipation 1WCatalogue Group C low Voltage cylindrical fusesStandards IEC 60269-1, IEC 60269-2Application For relays, contactors and motors protection in case of short-circuitFuse link CH10x38 CH CH10 25A 400V aM
