Fuse link CH10x38 aM 0,5A/500V 002621017 Obsolete

This product is obsolete and does not have a direct substitute, please contact our technical support in order to find a suitable replacement.

Specifications

ETI Code:
002621017
Description:
*CH10x38 aM 0,5A/500V
Class name:
Fuse link
efuse:
1
Type:
CH
Size:
CH10
Rated current (A):
0,5
Rated AC voltage (V):
500
Characteristics:
aM
Breaking capacity AC (kA):
100
Application:
For relays, contactors and motors protection in case of short-circuit
Dimensions:
10X38
Power dissipation (W):
0,4
Standards:
IEC 60269-1, IEC 60269-2

Documents

Product

EAN code for a single product
3838400030917
Net weight of the product
7.6  g
Customs tariff
85361010
logis_net_width
10  mm
logis_net_height
38  mm
logis_net_depth
10  mm

Level 1 Packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895169345
Basic packaging weight
0.08  kg

Level 2 Packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895169352
Transport packaging weight
4.1  kg
Pallet quantity
84000
Classification
EC002704
Class name
Cylindrical fuse
Size
10x38 mm
Nominal current
0.5A
Breaking capacity
100kA
ETIM Classification – Version 7.0
