Fuse link CH14x51 gPV 16A/1100V DC 002637185
Specifications
- ETI Code:
- 002637185
- Description:
- CH14x51 gPV 16A/1100V DC
- Class name:
- Fuse link
- efuse:
- 1
- Type:
- CH
- Size:
- CH14
- Rated current (A):
- 16
- Rated DC voltage (V):
- 1100
- Characteristics:
- gPV
- L/R (ms):
- 2
- Breaking capacity DC (kA):
- 30
- Application:
- For protection of photovoltaic modules
- Dimensions:
- 14x51
- Power dissipation (0,7xIn) (W):
- 1,4
- Power dissipation (W):
- 3,1
- Operating joule integral (A2s):
- 220
- Prearcing joule integral (A2s):
- 55
- Standards:
- IEC 60269-6
Documents
Logistic Data
Product
- EAN code for a single product
- 3838400056801
- Net weight of the product
- 18.6 g
- Customs tariff
- 85351000
- logis_net_width
- 14 mm
- logis_net_height
- 51 mm
- logis_net_depth
- 14 mm
Level 1 Packaging
- Basic packaging quantity
- 10
- EAN code for a basic packaging
- 3838895791553
- Basic packaging weight
- 0.199 kg
Level 2 Packaging
- Transport packaging quantity
- 200
- EAN code for a transport packaging
- 3838895791560
- Transport packaging weight
- 4.33 kg
- Pallet quantity
- 34000
ETIM Clasification
- Classification
- EC002704
- Class name
- Cylindrical fuse
- Application
- For protection of photovoltaic modules
- Construction size
- CH14
- Rated current
- 16
- Rated voltage DC
- 1100
- Size
- 14x51 mm
- Rated voltage
- Other
- Utilization category
- Other
- Nominal current
- 16A
