Fuse link CH22x58 gG 25A/690V 002640013

Specifications

ETI Code:
002640013
Description:
CH22x58 gG 25A/690V
Class name:
Fuse link
Type:
CH
Size:
CH22
Rated current (A):
25
Rated AC voltage (V):
690
Characteristics:
gG
Breaking capacity AC (kA):
80
Application:
For cable protection
Dimensions:
22x58
Power dissipation (W):
4,4
Standards:
IEC 60269-1, IEC 60269-2

Documents

Product

EAN code for a single product
3838895138990
Net weight of the product
0.52 kg
Customs tariff
85361050

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895138990
Basic packaging weight
0.52 kg
Basic packaging volume
0.33

Transport packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895165934
Transport packaging weight
26.3 kg
Transport packaging volume
16.5
Pallet quantity
26000
Pallet volume
858
Classification
EC002704
Class name
Cylindrical fuse
Breaking capacity
80kA
Nominal current
25A
Size
22x58 mm
Utilization category
Other
ETIM Classification – Version 7.0

Images & Diagrams

Software & drivers

Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
002640013Fuse link, CH22x58 gG 25A/690VCCylindrical fuse-linksCHCH22gGgGFuse links D, D0, CC fuse linksCH22X58 GG 25A/6Rated current 25AType CHSize CH22Product group C low Voltage cylindrical fusesCharacteristics gGRated AC voltage 690VDimensions 22x58Breaking capacity AC 80kAPower dissipation 4,4WCatalogue Group C low Voltage cylindrical fusesStandards IEC 60269-1, IEC 60269-2Application For cable protectionFuse link CH22x58 CH CH22 25A 690V gG
