Fuse link CH22x58 gG 50A/500V 002640019

Specifications

ETI Code:
002640019
Description:
CH22x58 gG 50A/500V
Class name:
Fuse link
Type:
CH
Size:
CH22
Rated current (A):
50
Rated AC voltage (V):
500
Characteristics:
gG
Breaking capacity AC (kA):
120
Application:
For cable protection
Dimensions:
22x58
Power dissipation (W):
7,7
Standards:
IEC 60269-1, IEC 60269-2

Documents

Product

EAN code for a single product
3838895581499
Net weight of the product
52 g
Customs tariff
85361050

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895139027
Basic packaging weight
0.52 kg
Basic packaging volume
0.33

Transport packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895165965
Transport packaging weight
26.3 kg
Transport packaging volume
16.5
Pallet quantity
26000
Pallet volume
858
Classification
EC002704
Class name
Cylindrical fuse
Application
For cable protection
Breaking capacity
120kA
Construction size
CH22
Max. rated operation voltage Ue AC
500
Nominal current
50A
Rated current
50
Size
22x58 mm
Utilization category
Other
ETIM Classification – Version 7.0
