Fuse link CH22x58 gG 63A/500V 002640021

Specifications

ETI Code:
002640021
Description:
CH22x58 gG 63A/500V
Class name:
Fuse link
Type:
CH
Size:
CH22
Rated current (A):
63
Rated AC voltage (V):
500
Characteristics:
gG
Breaking capacity AC (kA):
120
Application:
For cable protection
Dimensions:
22x58
Power dissipation (W):
8
Standards:
IEC 60269-1, IEC 60269-2

Documents

Product

EAN code for a single product
3838895139034
Net weight of the product
0.52 kg
Customs tariff
85361050

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895139034
Basic packaging weight
0.52 kg
Basic packaging volume
0.33

Transport packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895165972
Transport packaging weight
26.3 kg
Transport packaging volume
16.5
Pallet quantity
26000
Pallet volume
858
Classification
EC002704
Class name
Cylindrical fuse
Application
For cable protection
Breaking capacity
120kA
Construction size
CH22
Max. rated operation voltage Ue AC
500
Nominal current
63A
Nominal rated current
63
Size
22x58 mm
Utilization category
Other
ETIM Classification – Version 7.0

Images & Diagrams

Software & drivers

Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
002640021Fuse link, CH22x58 gG 63A/500VCCylindrical fuse-linksCHCH22gGgGFuse links D, D0, CC fuse linksCH22X58 GG 63A/5Rated current 63AType CHSize CH22Product group C low Voltage cylindrical fusesCharacteristics gGRated AC voltage 500VDimensions 22x58Breaking capacity AC 120kAPower dissipation 8WCatalogue Group C low Voltage cylindrical fusesStandards IEC 60269-1, IEC 60269-2Application For cable protectionFuse link CH22x58 CH CH22 63A 500V gG
