Fuse link CH22x58 aM 100A/500V 002641025 Obsolete

This product is obsolete and does not have a direct substitute, please contact our technical support in order to find a suitable replacement.

Specifications

ETI Code:
002641025
Description:
*CH22x58 aM 100A/500V
Class name:
Fuse link
efuse:
1
Type:
CH
Size:
CH22
Rated current (A):
100
Rated AC voltage (V):
500
Characteristics:
aM
Breaking capacity AC (kA):
120
Application:
For relays, contactors and motors protection in case of short-circuit
Dimensions:
22x58
Power dissipation (W):
6,4
Standards:
IEC 60269-1, IEC 60269-2

Documents

Product

EAN code for a single product
3838400031440
Net weight of the product
52  g
Customs tariff
85361090
logis_net_width
22  mm
logis_net_height
58  mm
logis_net_depth
22  mm

Level 1 Packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895169987
Basic packaging weight
0.52  kg

Level 2 Packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895169994
Transport packaging weight
26.3  kg
Pallet quantity
26000
Classification
EC002704
Class name
Cylindrical fuse
Size
22x58 mm
Nominal current
100A
Breaking capacity
120kA
ETIM Classification – Version 7.0
