Fuse link VVA3 7,2kV/2A 004221103

Specifications

ETI Code:
004221103
Description:
VVA3 7,2kV/2A
Class name:
Fuse link
Rated minimum breaking current (A):
12
Cold resistance (mΩ):
580
Rated current (A):
2
Type:
NEW VVA without striker
Size:
192
Characteristics:
Other
Rated AC voltage (V):
7200
Indicator:
Without
Breaking capacity AC (kA):
63
Power dissipation (W):
4
Application:
transformer protection, motor protection, capacitor bank protection, installation in ring main unit

Documents

Product

EAN code for a single product
3838895911579
Net weight of the product
1.2 kg
Customs tariff
85351000

Basic packaging

Basic packaging quantity
1
EAN code for a basic packaging
3838895911579
Basic packaging weight
1.2 kg
Basic packaging volume
5.14

Transport packaging

Transport packaging quantity
3
EAN code for a transport packaging
3838895911586
Transport packaging weight
4.22 kg
Transport packaging volume
15.42
Pallet quantity
180
Pallet volume
925.2
Classification
EC003507
Class name
Medium-/high voltage fuse
Breaking capacity
63kA
Diameter
53mm
Installation technique
Air
Length
192mm
Nominal rated current
2A
Nominal rated frequency
45…60Hz
Nominal rated voltage
7,2kV
Performance category according to IEC 60282-1
Back-up
Standard
IEC
Utilization category
Other
Voltage type
AC
With striker
No
ETIM Classification – Version 7.0
