Fuse link D01 UQ gR 10A/400V 004311004

Specifications

ETI Code:
004311004
Description:
D01 UQ gR 10A/400V
Class name:
Fuse link
Type:
D0
Size:
D01
Rated current (A):
10
Rated AC voltage (V):
400
Rated DC voltage (V):
250
Characteristics:
gR
Breaking capacity AC (kA):
50
Breaking capacity DC (kA):
8
Application:
For protection of semiconductor devices
Dimensions:
E14
Indicator:
Top fuse status indicator
Power dissipation (W):
4,2
Operating joule integral (A2s):
65
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838895013426
Net weight of the product
0.07 kg
Customs tariff
85361010

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895013426
Basic packaging weight
0.07 kg
Basic packaging volume
0.045

Transport packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895163992
Transport packaging weight
3.75 kg
Transport packaging volume
3.39
Pallet quantity
85000
Pallet volume
576.3
Classification
EC001642
Class name
D0-system fuse link
Colour code
Red
Construction size
D01
Rated current
10A
Rated voltage
400V
Utilization category
gR (general purpose semiconductor protection)
ETIM Classification – Version 7.0

Images & Diagrams

004311004Fuse link, D01 UQ gR 10A/400VUltra QuickSystem D0gR CharacteristicgR CharacteristicD01D01Fuse links for semi conductor protection ULTRA QUICKFuse links ULTRA QUICKD01 UQ GR 10A/40Rated current 10AType D0Rated voltage 400VSize D01Product group Semiconductor ProtectionCharacteristics gRRated AC voltage 400VRated DC voltage 250VDimensions E14Indicator Top fuse status indicatorBreaking capacity AC 50kABreaking capacity DC 8kAPower dissipation 4,2WCatalogue Group Semiconductor ProtectionStandards IEC 60269-4Operating joule integral 65A2sApplication For protection of semiconductor devicesFuse link D01 D0 D01 10A 400V 250V gR
