Fuse link D02 UQ gR 35A/400V 004312003

Specifications

ETI Code:
004312003
Description:
D02 UQ gR 35A/400V
Class name:
Fuse link
Type:
D0
Size:
D02
Rated current (A):
35
Rated AC voltage (V):
400
Rated DC voltage (V):
250
Characteristics:
gR
Breaking capacity AC (kA):
50
Breaking capacity DC (kA):
8
Application:
For protection of semiconductor devices
Dimensions:
E18
Indicator:
Top fuse status indicator
Power dissipation (W):
10
Operating joule integral (A2s):
1.000
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838895906964
Net weight of the product
13 g
Customs tariff
85361050

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895012702
Basic packaging weight
0.12 kg
Basic packaging volume
0.093

Transport packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895164036
Transport packaging weight
6.6 kg
Transport packaging volume
6.1
Pallet quantity
60000
Pallet volume
732
Classification
EC001642
Class name
D0-system fuse link
Colour code
Black
Construction size
D02
Rated current
35A
Rated voltage
400V
Utilization category
gR (general purpose semiconductor protection)
ETIM Classification – Version 7.0

Images & Diagrams

004312003Fuse link, D02 UQ gR 35A/400VUltra QuickSystem D0gR CharacteristicgR CharacteristicD02D02Fuse links for semi conductor protection ULTRA QUICKFuse links ULTRA QUICKD02 UQ GR 35A/40Rated current 35AType D0Rated voltage 400VSize D02Product group Semiconductor ProtectionCharacteristics gRRated AC voltage 400VRated DC voltage 250VDimensions E18Indicator Top fuse status indicatorBreaking capacity AC 50kABreaking capacity DC 8kAPower dissipation 10WCatalogue Group Semiconductor ProtectionStandards IEC 60269-4Operating joule integral 1.000A2sApplication For protection of semiconductor devicesFuse link D02 D0 D02 35A 400V 250V gR
