Fuse link BS17UQ/63/50A/690V 004750612 Obsolete

This product is obsolete and does not have a direct substitute, please contact our technical support in order to find a suitable replacement.

Specifications

ETI Code:
004750612
Description:
*BS17UQ/63/50A/690V
Class name:
Fuse link
efuse:
1
Product group:
Semiconductor Protection
Type:
BS
Size:
BS17
Rated current (A):
50
Rated AC voltage (V):
690
Rated DC voltage (V):
350
Characteristics:
aR
Breaking capacity AC (kA):
100
Breaking capacity DC (kA):
100
Application:
For protection of semiconductor devices
Dimensions:
screw 63mm
Power dissipation (W):
9,5
Operating joule integral (A2s):
1.300
Standards:
IEC 60269-4, BS88 Part 4

Documents

Product

EAN code for a single product
3838400053114
Net weight of the product
0.059  kg
Customs tariff
85361050
logis_net_width
17  mm
logis_net_height
77  mm
logis_net_depth
19  mm

Level 1 Packaging

Basic packaging quantity
5
EAN code for a basic packaging
3838895416142
Basic packaging weight
0.211  kg

Level 2 Packaging

Transport packaging quantity
10
EAN code for a transport packaging
3838895361541
Transport packaging weight
0.585  kg
Pallet quantity
13680
Classification
EC002704
Class name
Cylindrical fuse
Construction size
BS17
Max. rated operation voltage Ue AC
690
Rated current
50
Rated voltage DC
350
Application
For protection of semiconductor devices
Size
Other
Utilization category
Other
Nominal current
50A
Breaking capacity
100kA
ETIM Classification – Version 7.0
