Fuse link BS17UQ/63/63A/690V 004750615

Specifications

ETI Code:
004750615
Description:
BS17UQ/63/63A/690V
Class name:
Fuse link
Type:
BS
Size:
BS17
Rated current (A):
63
Rated AC voltage (V):
690
Rated DC voltage (V):
350
Characteristics:
aR
Breaking capacity AC (kA):
100
Breaking capacity DC (kA):
100
Application:
For protection of semiconductor devices
Dimensions:
screw 63mm
Power dissipation (W):
11,5
Operating joule integral (A2s):
2.100
Standards:
IEC 60269-4, BS88 Part 4

Documents

Product

EAN code for a single product
3838895416166
Net weight of the product
0.211 kg
Customs tariff
85361050

Basic packaging

Basic packaging quantity
5
EAN code for a basic packaging
3838895416166
Basic packaging weight
0.211 kg
Basic packaging volume
0.014

Transport packaging

Transport packaging quantity
10
EAN code for a transport packaging
3838895361565
Transport packaging weight
0.585 kg
Transport packaging volume
0.029
Pallet quantity
13680
Pallet volume
39.672
Classification
EC002704
Class name
Cylindrical fuse
Breaking capacity
100kA
Nominal current
63A
Size
Other
Utilization category
Other
ETIM Classification – Version 7.0
