002471824
*TER-9 230V Control relay
- ETI Code:
- 002471824
- Category:
- Multifunctional digital thermostat TER-9
- Catalogue Group:
- Temperature monitoring relays
- Catalogue Subgroup:
- Multifunction digital thermostat
- Rated Frequency:
- 50 Hz
- IP rating:
- IP20
- Type description:
- Multifunctional digital thermostat TER-9
- Function:
- Monitoring and Control relays
- Supply Voltage:
- 230 V
- Temperature range:
- -40-110 °C
- Sensor Type:
- termistor NTC 12Ω at 25°C
- Number of contacts:
- 1
- Rated current:
- 8 A
- Voltage type:
- AC
- No. of CO contacts:
- 2
- Type of contacts:
- 1xCO
- Maximum load capacity at AC1:
- 2,500 VA
7 Documents
11 Logistics
Product
- Net weight of the product
- 0.13 kg
- Net width
- 35 mm
- Net height
- 94.9 mm
- Net depth
- 64.12 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838895426691
- Transport packaging weight
- 0.13 kg
- Transport packaging volume
- 0.21 dm³
- Pallet quantity
- 6,154 pcs
- Customs tariff
- 85364900
20 ETIM
- Weekly program
- Yes
- Model
- Digital
- Number of channels
- 2
- Autonomy
- 26,280 h
- Degree of protection (IP)
- IP20
- Contact type
- Change-over contact
- Automatic switching summer-/winter time
- Yes
- Assembly depth
- 65 mm
- Nominal switching current at 250 V, potential free
- 8 A
- 24 h program
- Yes
- Sensor type
- Remote sensor
- Text guidance in display
- Yes
- Standby power consumption (solstandby)
- 3 W
- Width in number of modular spacings
- 2
- Rated frequency(Min)
- 50 Hz
- Rated voltage(Min)
- 230 V
- Adjustment range comfort(Min)
- -40 °C
- Rated voltage(Max)
- 230 V
- Adjustment range comfort(Max)
- 110 °C
- Rated frequency(Max)
- 60 Hz
ETIM Classification – Version 9.0
