001101417
4XP160 3-5 Flush mounted enclosure
- ETI Code:
- 001101417
- Type of Installation:
- Flush mounted
- Key locks:
- Two locks with a key 1333 code
- Frame size (Nr. of rows):
- 5
- Ambient temperature:
- -5/40 °C
- Rated AC voltage:
- 690 V
- Type of door:
- Full, Metal door
- Isolation class:
- I
- Network system:
- 1 phase and 3 phase system
- Standards:
- IEC/EN 62208, IEC/EN 60529, IEC/EN 62262, IEC/EN 61439-1
- Catalogue Group:
- SOLID GSX Enclosures
- Working Temperature:
- -5-40 °C
- Frame Size:
- 160
- Directives:
- RoHS
- To use with:
- SOLID GSX system
- Rows (legacy):
- 5
- Surface finish:
- Powder coated steel
- Function:
- Enclosure
- Type description:
- Flush mounted enclosure
- Protection Class:
- I
- IP rating:
- IP42
- Mechanical resistance:
- IK10
- Height:
- 860 mm
- Width:
- 860 mm
- Depth:
- 160 mm
- Application:
- Indoor use
- Color:
- RAL 7035
- Rated current:
- 250 A
10 Logistics
Product
- Net depth
- 160 mm
- Net weight of the product
- 20.344 kg
- Net width
- 860 mm
- Net height
- 860 mm
- Stock unit of measure
- pcs
Basic Packaging
- EAN code for a basic packaging
- 5904723019712
- Basic packaging weight
- 21.77 kg
- Basic packaging volume
- 137.81 dm³
- Basic packaging quantity
- 1 pcs
Transport Packaging
- Customs tariff
- 85381000
18 ETIM
- Built-in depth
- 160 mm
- Nominal current (In)
- 250 A
- Surface protection
- Powder coating
- Width
- 860 mm
- Degree of protection (IP)
- IP42
- Mounting method
- Flush-mounted
- Impact strength
- IK10
- Number of modules
- 180
- Protection class
- I
- With lock
- Yes
- Number of rows
- 5
- Housing material
- Steel
- Depth
- 160 mm
- Colour
- Other
- Type of door
- Single
- Height
- 860 mm
- Width in number of modular spacings
- 36
- RAL-number
- 7,035
ETIM Classification – Version 9.0
