002631008
Obsolete
*CH14x51 aM 12A/690V Fuse link
- ETI Code:
- 002631008
- Catalogue Group:
- C low Voltage cylindrical fuses
- Product group:
- C low Voltage cylindrical fuses
- Type description:
- CH
- Fuse type:
- CH
- Size:
- 14x51
- Rated current:
- 12 A
- Rated AC voltage:
- 690 V
- Time-Current Characteristic:
- aM
- Breaking capacity AC:
- 80 kA
- Application:
- For relays, contactors and motors protection in case of short-circuit
- Power dissipation:
- 0.8 W
- Standards:
- IEC 60269-1, IEC 60269-2
16 Logistics
Product
- Net depth
- 14.3 mm
- Net weight of the product
- 18.75 g
- Net width
- 14.3 mm
- Net height
- 51 mm
- Stock unit of measure
- pcs
- EAN code for a single product
- 3838895906605
Basic Packaging
- EAN code for a basic packaging
- 3838895169680
- Basic packaging weight
- 0.186 kg
- Basic packaging volume
- 0.126 dm³
- Basic packaging quantity
- 10 pcs
Transport Packaging
- Transport packaging weight
- 9.8 kg
- Transport packaging volume
- 6.4 dm³
- Transport packaging quantity
- 500 pcs
- Customs tariff
- 85361050
- EAN code for a transport packaging
- 3838895169697
- Pallet quantity
- 85,000 pcs
2 ETIM
- Size
- 14x51 mm
- Breaking capacity
- 80 kA
ETIM Classification – Version 9.0
