002652042
CH22x58 aM 10A/690V Fuse link
- ETI Code:
- 002652042
- Type description:
- CH
- Fuse type:
- CH
- Size:
- 22x58
- Rated current:
- 10 A
- Rated AC voltage:
- 690 V
- Time-Current Characteristic:
- aM
- Breaking capacity AC:
- 120 kA
- Application:
- For relays, contactors and motors protection in case of short-circuit
- Power dissipation:
- 0.75 W
- Standards:
- IEC 60269-1, IEC 60269-2
22 Logistics
Product
- Net depth
- 22.2 mm
- Net weight of the product
- 0.054 kg
- Net width
- 22.2 mm
- Net height
- 58 mm
- Stock unit of measure
- pcs
- EAN code for a single product
- 3838400115584
Basic Packaging
- EAN code for a basic packaging
- 3838400096197
- Basic packaging weight
- 0.559 kg
- Basic Packaging Dimensions Depth
- 117 mm
- Basic Packaging Dimensions Height
- 23 mm
- Basic packaging volume
- 0.32 dm³
- Basic Packaging Dimensions Width
- 119 mm
- Basic packaging quantity
- 10 pcs
Transport Packaging
- Transport packaging weight
- 14.415 kg
- Transport packaging volume
- 36 dm³
- Transport packaging quantity
- 250 pcs
- Customs tariff
- 85361050
- Transport Packaging Dimensions Height
- 300 mm
- Transport Packaging Dimensions Width
- 300 mm
- Transport Packaging Dimensions Depth
- 400 mm
- EAN code for a transport packaging
- 3838400096203
- Pallet quantity
- 6,000 pcs
8 ETIM
- Voltage type
- AC
- Rated operating frequency(Min)
- 50 Hz
- Size
- 22x58 mm
- Rated operating frequency(Max)
- 50 Hz
- Breaking capacity
- 120 kA
- Rated voltage
- 690 V
- Rated current
- 10 A
- Utilization category
- aM (switchgear protection)
ETIM Classification – Version 9.0
