006711025
CH22x58/P gG 25A/690V Fuse link
- ETI Code:
- 006711025
- Product group:
- C low Voltage cylindrical fuses
- Catalogue Group:
- C low Voltage cylindrical fuses
- Type description:
- CH
- Fuse type:
- CH
- Size:
- 22x58
- Rated current:
- 25 A
- Rated AC voltage:
- 690 V
- Time-Current Characteristic:
- gG
- Breaking capacity AC:
- 80 kA
- Application:
- For cable protection
- Indicator:
- Striker pin status indicator
- Power dissipation:
- 3.3 W
- Standards:
- IEC 60269-1, IEC 60269-2
22 Logistics
Product
- EAN code for a single product
- 3838400170811
- Net weight of the product
- 0.045 kg
- Net width
- 22.2 mm
- Net height
- 65.5 mm
- Net depth
- 22.2 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 10 pcs
- EAN code for a basic packaging
- 8024873005032
- Basic packaging weight
- 0.54 kg
- Basic Packaging Dimensions Height
- 24 mm
- Basic Packaging Dimensions Width
- 114 mm
- Basic Packaging Dimensions Depth
- 120 mm
- Basic packaging volume
- 0.328 dm³
Transport Packaging
- Transport packaging quantity
- 50 pcs
- EAN code for a transport packaging
- 8024873061243
- Transport packaging weight
- 2.7 kg
- Transport Packaging Dimensions Height
- 120 mm
- Transport Packaging Dimensions Width
- 114 mm
- Transport Packaging Dimensions Depth
- 120 mm
- Transport packaging volume
- 1.642 dm³
- Pallet quantity
- 11,100 pcs
- Customs tariff
- 85361050
4 ETIM
- Size
- 22x58 mm
- Breaking capacity
- 80 kA
- Rated current
- 25 A
- Utilization category
- Other
ETIM Classification – Version 9.0
