002312403
DII gG 6A/500V Fuse link
- ETI Code:
- 002312403
- Catalogue Group:
- D Low voltage Fuses
- Application:
- For cable protection
- Product group:
- D Low voltage Fuses
- Type description:
- D
- Size:
- DII
- Time-Current Characteristic:
- gG
- Rated AC voltage:
- 500 V
- Rated DC voltage:
- 250 V
- Rated current:
- 6 A
- Power dissipation:
- 2.2 W
- Breaking capacity AC:
- 50 kA
- Breaking capacity DC:
- 8 kA
- Fuse type:
- D
- Indicator:
- Top fuse status indicator
- Standards:
- DIN EN 60269-1, DIN EN 60269-3
22 Logistics
Product
- Net depth
- 50 mm
- Net weight of the product
- 25 g
- Net width
- 22 mm
- Net height
- 22 mm
- Stock unit of measure
- pcs
- EAN code for a single product
- 5904722905214
Basic Packaging
- EAN code for a basic packaging
- 3838895000037
- Basic packaging weight
- 0.133 kg
- Basic Packaging Dimensions Depth
- 0.023 m
- Basic Packaging Dimensions Height
- 0.05 m
- Basic packaging volume
- 0 m³
- Basic Packaging Dimensions Width
- 0.11 m
- Basic packaging quantity
- 5 pcs
Transport Packaging
- Transport packaging weight
- 13.66 kg
- Transport packaging volume
- 0.017 m³
- Transport packaging quantity
- 500 pcs
- Customs tariff
- 85361010
- Transport Packaging Dimensions Height
- 0.25 m
- Transport Packaging Dimensions Width
- 0.235 m
- Transport Packaging Dimensions Depth
- 0.295 m
- EAN code for a transport packaging
- 3838895163503
- Pallet quantity
- 26,000 pcs
5 ETIM
- Colour code
- Green
- Release characteristic
- Time-lag (T)
- Construction size
- DII
- Rated voltage
- 250 V
- Rated current
- 6 A
ETIM Classification – Version 9.0
