STV D02 63A 3p Switch disconnector fuse
- ETI Code:
- 002271004
- To use with:
- D0 fuse-links
- Breaking capacity AC:
- 50 kA
- Catalogue Group:
- LV-fuse disconnector
- Ambient temperature:
- -5/40 °C
- Standards:
- IEC60269-1, IEC60269-3, IEC60947-1, IEC60947-3
- Application:
- Residential and industrial installation
- Type description:
- STV D02
- Type of Installation:
- DIN rail
- Utilization category:
- AC-22A
- Size:
- D02
- Product group:
- LV-fuse disconnector
- Rated AC voltage:
- 400 V
- Rated DC voltage:
- 110 V
- Rated current:
- 63 A
- Number of poles:
- 3
7 Documents
22 Logistics
Product
- EAN code for a single product
- 3838400030535
- Net weight of the product
- 0.439 kg
- Net width
- 80.4 mm
- Net height
- 89.2 mm
- Net depth
- 69.22 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 4 pcs
- EAN code for a basic packaging
- 3838895135302
- Basic packaging weight
- 1.822 kg
- Basic Packaging Dimensions Height
- 0.083 m
- Basic Packaging Dimensions Width
- 0.097 m
- Basic Packaging Dimensions Depth
- 0.327 m
- Basic packaging volume
- 0.003 m³
Transport Packaging
- Transport packaging quantity
- 32 pcs
- EAN code for a transport packaging
- 3838895162872
- Transport packaging weight
- 15.125 kg
- Transport Packaging Dimensions Height
- 0.215 m
- Transport Packaging Dimensions Width
- 0.368 m
- Transport Packaging Dimensions Depth
- 0.368 m
- Transport packaging volume
- 0.029 m³
- Pallet quantity
- 768 pcs
- Customs tariff
- 85389099
4 ETIM
- Construction size
- D02
- Number of poles
- 3
- Rated voltage
- 400 V
- Rated current
- 63 A
