Semiconductor Fuse links CH ULTRA QUICK - Products & Solutions

CH10x38 aR 6A/600V

Class name: Fuse link
Type description: CH
Size: 10x38
Rated current: 6 A
Time-Current Characteristic: aR
Rated AC voltage: 600 V
Rated DC voltage: 700 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 1.5 W
Operating joule integral (A2s): 30
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH10x38 aR 8A/600V

Class name: Fuse link
Type description: CH
Size: 10x38
Rated current: 8 A
Time-Current Characteristic: aR
Rated AC voltage: 600 V
Rated DC voltage: 700 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 2 W
Operating joule integral (A2s): 50
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH10x38 aR 10A/600V

Class name: Fuse link
Type description: CH
Size: 10x38
Rated current: 10 A
Time-Current Characteristic: aR
Rated AC voltage: 600 V
Rated DC voltage: 700 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 2.5 W
Operating joule integral (A2s): 70
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH10x38 aR 12A/600V

Class name: Fuse link
Type description: CH
Size: 10x38
Rated current: 12 A
Time-Current Characteristic: aR
Rated AC voltage: 600 V
Rated DC voltage: 700 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 3 W
Operating joule integral (A2s): 120
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH10x38 aR 16A/600V

Class name: Fuse link
Type description: CH
Size: 10x38
Rated current: 16 A
Time-Current Characteristic: aR
Rated AC voltage: 600 V
Rated DC voltage: 700 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 3.5 W
Operating joule integral (A2s): 150
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH10x38 aR 20A/600V

Class name: Fuse link
Type description: CH
Size: 10x38
Rated current: 20 A
Time-Current Characteristic: aR
Rated AC voltage: 600 V
Rated DC voltage: 700 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 4.8 W
Operating joule integral (A2s): 260
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH10x38 aR 25A/600V

Class name: Fuse link
Type description: CH
Size: 10x38
Rated current: 25 A
Time-Current Characteristic: aR
Rated AC voltage: 600 V
Rated DC voltage: 700 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 6 W
Operating joule integral (A2s): 290
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH10x38 aR 32A/600V

Class name: Fuse link
Type description: CH
Size: 10x38
Rated current: 32 A
Time-Current Characteristic: aR
Rated AC voltage: 600 V
Rated DC voltage: 400 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 7.5 W
Operating joule integral (A2s): 600
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH14x51 aR 10A/690V

Class name: Fuse link
Type description: CH
Size: 14x51
Rated current: 10 A
Time-Current Characteristic: aR
Rated AC voltage: 690 V
Rated DC voltage: 700 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 4 W
Operating joule integral (A2s): 22
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH14x51 aR 12A/690V

Class name: Fuse link
Type description: CH
Size: 14x51
Rated current: 12 A
Time-Current Characteristic: aR
Rated AC voltage: 690 V
Rated DC voltage: 700 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 5 W
Operating joule integral (A2s): 50
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH14x51 aR 16A/690V

Class name: Fuse link
Type description: CH
Size: 14x51
Rated current: 16 A
Time-Current Characteristic: aR
Rated AC voltage: 690 V
Rated DC voltage: 700 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 5.5 W
Operating joule integral (A2s): 75
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH14x51 aR 20A/690V

Class name: Fuse link
Type description: CH
Size: 14x51
Rated current: 20 A
Time-Current Characteristic: aR
Rated AC voltage: 690 V
Rated DC voltage: 700 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 6 W
Operating joule integral (A2s): 180
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH14x51 aR 25A/690V

Class name: Fuse link
Type description: CH
Size: 14x51
Rated current: 25 A
Time-Current Characteristic: aR
Rated AC voltage: 690 V
Rated DC voltage: 700 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 7 W
Operating joule integral (A2s): 320
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH14x51 aR 32A/690V

Class name: Fuse link
Type description: CH
Size: 14x51
Rated current: 32 A
Time-Current Characteristic: aR
Rated AC voltage: 690 V
Rated DC voltage: 700 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 7.6 W
Operating joule integral (A2s): 600
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH14x51 aR 40A/600V

Class name: Fuse link
Type description: CH
Size: 14x51
Rated current: 40 A
Time-Current Characteristic: aR
Rated AC voltage: 600 V
Rated DC voltage: 700 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 8 W
Operating joule integral (A2s): 750
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH14x51 aR 50A/500V

Class name: Fuse link
Type description: CH
Size: 14x51
Rated current: 50 A
Time-Current Characteristic: aR
Rated AC voltage: 500 V
Rated DC voltage: 700 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 9 W
Operating joule integral (A2s): 1,800
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH22x58 aR 20A/690V

Class name: Fuse link
Type description: CH
Size: 22x58
Rated current: 20 A
Time-Current Characteristic: aR
Rated AC voltage: 690 V
Rated DC voltage: 500 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 5.6 W
Operating joule integral (A2s): 260
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH22x58 aR 25A/690V

Class name: Fuse link
Type description: CH
Size: 22x58
Rated current: 25 A
Time-Current Characteristic: aR
Rated AC voltage: 690 V
Rated DC voltage: 500 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 5.6 W
Operating joule integral (A2s): 410
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH22x58 aR 32A/690V

Class name: Fuse link
Type description: CH
Size: 22x58
Rated current: 32 A
Time-Current Characteristic: aR
Rated AC voltage: 690 V
Rated DC voltage: 500 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 7 W
Operating joule integral (A2s): 605
Standards: IEC 60269-4
Application: For protection of semiconductor devices

CH22x58 aR 40A/690V

Class name: Fuse link
Type description: CH
Size: 22x58
Rated current: 40 A
Time-Current Characteristic: aR
Rated AC voltage: 690 V
Rated DC voltage: 500 V
Breaking capacity AC: 200 kA
Breaking capacity DC: 50 kA
Power dissipation: 8.5 W
Operating joule integral (A2s): 750
Standards: IEC 60269-4
Application: For protection of semiconductor devices
