002625011
CH10x38 aR 20A/600V Fuse link
- ETI Code:
- 002625011
- Product group:
- Semiconductor Protection
- Catalogue Group:
- Semiconductor Protection
- Fuse type:
- CH
- Type description:
- CH
- Size:
- 10x38
- Rated current:
- 20 A
- Time-Current Characteristic:
- aR
- Rated AC voltage:
- 600 V
- Rated DC voltage:
- 700 V
- Breaking capacity AC:
- 200 kA
- Breaking capacity DC:
- 50 kA
- Power dissipation:
- 4.8 W
- Operating joule integral (A2s):
- 260
- Standards:
- IEC 60269-4
- Application:
- For protection of semiconductor devices
5 Documents
12 Logistics
Product
- EAN code for a single product
- 3838895362821
- Net weight of the product
- 0.026 kg
- Net width
- 10.2 mm
- Net height
- 38.2 mm
- Net depth
- 10.2 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 10 pcs
- EAN code for a transport packaging
- 3838895356202
- Transport packaging weight
- 0.341 kg
- Transport packaging volume
- 0.04 dm³
- Pallet quantity
- 75,000 pcs
- Customs tariff
- 85361050
4 ETIM
- Size
- 10x32 mm
- Breaking capacity
- 200 kA
- Rated current
- 20 A
- Utilization category
- Other
ETIM Classification – Version 9.0
