NHS2/394/M aR 100A/4000V DC Fuse link
- ETI Code:
- 004735601
- Type description:
- NH-S
- Fuse type:
- NH-S
- Size:
- NH2
- Rated current:
- 100 A
- Time-Current Characteristic:
- aR
- Indicator:
- Centre trip indicator for MK
- Rated DC voltage:
- 4000 V
- Breaking capacity DC:
- 30 kA
- L/R:
- 15 ms
- Power dissipation:
- 58 W
- Prearcing joule integral (A2s):
- 2,300
- Operating joule integral (A2s):
- 20,000
- Standards:
- IEC 60269-4, IEC 60077-5
- Application:
- Fuse link for DC link protection of railway inverter.
16 Logistics
Product
- Net depth
- 73 mm
- Net weight of the product
- 3,500 g
- Net width
- 66 mm
- Net height
- 419 mm
- Stock unit of measure
- pcs
- EAN code for a single product
- 3838400178107
Basic Packaging
- Basic packaging quantity
- 1 pcs
Transport Packaging
- Transport packaging weight
- 3.698 kg
- Transport packaging volume
- 0.005 m³
- Transport packaging quantity
- 1 pcs
- Customs tariff
- 85351000
- Transport Packaging Dimensions Height
- 0.088 m
- Transport Packaging Dimensions Width
- 0.534 m
- Transport Packaging Dimensions Depth
- 0.104 m
- EAN code for a transport packaging
- 3838895689737
- Pallet quantity
- 140 pcs
8 ETIM
- Voltage type
- DC
- Fuse construction type according to IEC 60269
- NH2
- Power loss at rated current
- 58 W
- Rated switching capacity DC
- 30 kA
- Type of fuse status indicator
- Other
- Rated current
- 100 A
- Rated voltage DC
- 4,000
- Utilization category
- aR (accompanied semiconductor protection)
