NH1 UQ01 aR 160A/1000V Fuse link
- ETI Code:
- 004303216
- Fuse type:
- NH
- Size:
- NH1
- Rated current:
- 160 A
- Time-Current Characteristic:
- aR
- Indicator:
- Top fuse status indicator
- Rated AC voltage:
- 1000 V
- Breaking capacity AC:
- 200 kA
- Power dissipation:
- 35 W
- Operating joule integral (A2s):
- 17,000
- Standards:
- IEC 60269-4
- Application:
- For protection of semiconductor devices
5 Documents
22 Logistics
Product
- EAN code for a single product
- 3838895756781
- Net weight of the product
- 640 g
- Net width
- 51 mm
- Net height
- 135 mm
- Net depth
- 63 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 3 pcs
- EAN code for a basic packaging
- 3838895466031
- Basic packaging weight
- 1.996 kg
- Basic Packaging Dimensions Height
- 0.079 m
- Basic Packaging Dimensions Width
- 0.17 m
- Basic Packaging Dimensions Depth
- 0.17 m
- Basic packaging volume
- 0.002 m³
Transport Packaging
- Transport packaging quantity
- 24 pcs
- EAN code for a transport packaging
- 3838895713128
- Transport packaging weight
- 16.514 kg
- Transport Packaging Dimensions Height
- 0.23 m
- Transport Packaging Dimensions Width
- 0.38 m
- Transport Packaging Dimensions Depth
- 0.38 m
- Transport packaging volume
- 0.033 m³
- Pallet quantity
- 576 pcs
- Customs tariff
- 85361090
8 ETIM
- Rated switching capacity AC
- 200 kA
- Voltage type
- AC
- Fuse construction type according to IEC 60269
- NH1
- Rated voltage AC
- 1,000
- Power loss at rated current
- 35 W
- Type of fuse status indicator
- Top fuse status indicator
- Rated current
- 160 A
- Utilization category
- aR (accompanied semiconductor protection)
