NH2/K UQ2 gR 224A/690V Fuse link
- ETI Code:
- 004724244
- Fuse type:
- NH-K
- Size:
- NH2
- Rated current:
- 224 A
- Time-Current Characteristic:
- gR
- Indicator:
- Striker pin status indicator
- Rated AC voltage:
- 690 V
- Breaking capacity AC:
- 200 kA
- Power dissipation:
- 36.8 W
- Operating joule integral (A2s):
- 60,000
- Standards:
- IEC 60269-4
- Application:
- For protection of semiconductor devices
5 Documents
22 Logistics
Product
- EAN code for a single product
- 3838895768081
- Net weight of the product
- 700 g
- Net width
- 55 mm
- Net height
- 151 mm
- Net depth
- 71 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 3 pcs
- EAN code for a basic packaging
- 3838895505488
- Basic packaging weight
- 2.176 kg
- Basic Packaging Dimensions Height
- 0.079 m
- Basic Packaging Dimensions Width
- 0.17 m
- Basic Packaging Dimensions Depth
- 0.17 m
- Basic packaging volume
- 0.002 m³
Transport Packaging
- Transport packaging quantity
- 24 pcs
- EAN code for a transport packaging
- 3838895768098
- Transport packaging weight
- 17.954 kg
- Transport Packaging Dimensions Height
- 0.23 m
- Transport Packaging Dimensions Width
- 0.38 m
- Transport Packaging Dimensions Depth
- 0.38 m
- Transport packaging volume
- 0.033 m³
- Pallet quantity
- 576 pcs
- Customs tariff
- 85361090
8 ETIM
- Rated switching capacity AC
- 200 kA
- Voltage type
- AC
- Fuse construction type according to IEC 60269
- NH2
- Rated voltage AC
- 690
- Power loss at rated current
- 36.8 W
- Type of fuse status indicator
- Other
- Rated current
- 224 A
- Utilization category
- gR (general purpose semiconductor protection)
