NHS3/140/M UQ01 aR 450A/1500V Fuse link
- ETI Code:
- 004735153
- Fuse type:
- NH-S
- Size:
- NH3
- Rated current:
- 450 A
- Time-Current Characteristic:
- aR
- Indicator:
- Centre trip indicator for MK
- Rated AC voltage:
- 1500 V
- Breaking capacity AC:
- 50 kA
- Power dissipation:
- 135 W
- Operating joule integral (A2s):
- 390,000
- Standards:
- IEC 60269-4
- Application:
- For protection of semiconductor devices
5 Documents
21 Logistics
Product
- Net weight of the product
- 1,600 g
- Net width
- 73 mm
- Net height
- 169 mm
- Net depth
- 73 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 1 pcs
- EAN code for a basic packaging
- 3838400140975
- Basic packaging weight
- 1.66 kg
- Basic Packaging Dimensions Height
- 0.094 m
- Basic Packaging Dimensions Width
- 0.213 m
- Basic Packaging Dimensions Depth
- 0.078 m
- Basic packaging volume
- 0.002 m³
Transport Packaging
- Transport packaging quantity
- 9 pcs
- EAN code for a transport packaging
- 3838895637318
- Transport packaging weight
- 15.29 kg
- Transport Packaging Dimensions Height
- 0.255 m
- Transport Packaging Dimensions Width
- 0.295 m
- Transport Packaging Dimensions Depth
- 0.235 m
- Transport packaging volume
- 0.018 m³
- Pallet quantity
- 468 pcs
- Customs tariff
- 85351000
8 ETIM
- Rated switching capacity AC
- 50 kA
- Voltage type
- AC
- Fuse construction type according to IEC 60269
- NH3
- Rated voltage AC
- 1,500
- Power loss at rated current
- 135 W
- Type of fuse status indicator
- Other
- Rated current
- 450 A
- Utilization category
- aR (accompanied semiconductor protection)
