002050615
Obsolete
* LIMAT-2-SD 2p AC C25/0.03 RCBO
- ETI Code:
- 002050615
- Has overvoltage protection:
- No
- Rated AC voltage:
- 230 V
- Rated DC voltage:
- 230 V
- Depth:
- 68 mm
- Number of poles:
- 2
- IP rating:
- IP20
- Tripping characteristic:
- C
- Function:
- RCBO
- Short circuit capacity:
- 10 kA
- Rated current:
- 25 A
- Catalogue Group:
- LIMAT2 SD Residual current circuit breakers with
- Rated residual current:
- 0.03 A
3 Documents
12 Logistics
Product
- Net weight of the product
- 0.4 kg
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 1 pcs
- EAN code for a basic packaging
- 3838895464167
- Basic packaging weight
- 0.4 kg
- Basic packaging volume
- 0.646 dm³
Transport Packaging
- Transport packaging quantity
- 16 pcs
- EAN code for a transport packaging
- 3838895464174
- Transport packaging weight
- 6.7 kg
- Transport packaging volume
- 16 dm³
- Pallet quantity
- 960 pcs
- Customs tariff
- 85362010
12 ETIM
- Built-in depth
- 68 mm
- Leakage current type
- AC
- Degree of protection (IP)
- IP20
- Release characteristic
- C
- Rated fault current
- 0.03 A
- Number of poles (total)
- 2
- Concurrently switching neutral conductor
- Yes
- Number of protected poles
- 2
- Rated voltage
- 230 V
- Current limiting class
- 3
- Rated current
- 25 A
- Width in number of modular spacings
- 4
ETIM Classification – Version 9.0
