Residual and overcurrent protection RCBO

Introduction

RCBOs, or Residual Current Circuit Breakers with Integral Overcurrent Protection, represent a significant advancement in electrical safety. By merging the functions of a Miniature Circuit Breaker (MCB) and a Residual Current Circuit Breaker (RCCB), they provide comprehensive protection for both people and electrical systems in a single compact unit. RCBOs are highly recommended in various settings, including residential, commercial, and industrial electrical installations, where enhanced safety is paramount.

KZS-1M-FN A B6/0.03

Class name: RCBO
Rated current: 6 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: B
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A B10/0.03

Class name: RCBO
Rated current: 10 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: B
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A B13/0.03

Class name: RCBO
Rated current: 13 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: B
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A B16/0.03

Class name: RCBO
Rated current: 16 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: B
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A B20/0.03

Class name: RCBO
Rated current: 20 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: B
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A B25/0.03

Class name: RCBO
Rated current: 25 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: B
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A B32/0.03

Class name: RCBO
Rated current: 32 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: B
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A B40/0.03

Class name: RCBO
Rated current: 40 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: B
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A B45/0.03

Class name: RCBO
Rated current: 45 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: B
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A C6/0.03

Class name: RCBO
Rated current: 6 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: C
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A C10/0.03

Class name: RCBO
Rated current: 10 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: C
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A C13/0.03

Class name: RCBO
Rated current: 13 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: C
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A C16/0.03

Class name: RCBO
Rated current: 16 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: C
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A C20/0.03

Class name: RCBO
Rated current: 20 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: C
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A C25/0.03

Class name: RCBO
Rated current: 25 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: C
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A C32/0.03

Class name: RCBO
Rated current: 32 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: C
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A C40/0.03

Class name: RCBO
Rated current: 40 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: C
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN A C45/0.03

Class name: RCBO
Rated current: 45 A
Residual current type: A
Rated residual current: 0.03 A
Tripping characteristic: C
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN AC B6/0.03

Class name: RCBO
Rated current: 6 A
Residual current type: AC
Rated residual current: 0.03 A
Tripping characteristic: B
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009

KZS-1M-FN AC B10/0.03

Class name: RCBO
Rated current: 10 A
Residual current type: AC
Rated residual current: 0.03 A
Tripping characteristic: B
Number of poles: 1+N
Short circuit capacity: 10 kA
Rated cross section: 1-25 mm²
Standards: IEC 61009
