004671355
EB2 250/4LE 40A 4p Molded Case Circuit Breaker
- ETI Code:
- 004671355
- Application:
- 60947
- Short circuit capacity:
- 36 kA
- Rated current:
- 40 A
- Number of poles:
- 4
- Connection type:
- front connection
- Rated impulse withstand voltage Uimp:
- 8 kV
- Rated short-circuit breaking capacity at 415V Icu/Ics:
- 36 kA
- Rated operational voltage (AC):
- 690 V
- Rated Insulation Voltage:
- 800 V
- Thermal Adjustment:
- 0,4-1
- Magnetic adjustment:
- adjustable
- Adjustable or fixed:
- adjustable
- Standards:
- 60947
- Function:
- MCCB
- Catalogue Group:
- EB2
- Frame Size:
- 250A
5 Documents
14 Logistics
Product
- Net weight of the product
- 3.3 kg
- Net width
- 140 mm
- Net height
- 165 mm
- Net depth
- 92 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838895755074
- Transport packaging weight
- 3.3 kg
- Transport Packaging Dimensions Height
- 150 mm
- Transport Packaging Dimensions Width
- 170 mm
- Transport Packaging Dimensions Depth
- 155 mm
- Transport packaging volume
- 3.952 dm³
- Pallet quantity
- 200 pcs
- Customs tariff
- 85362090
