EB2S 160/1LF 125A 1p Molded Case Circuit Breaker
- ETI Code:
- 004671010
- Application:
- 60947-2
- Function:
- MCCB
- Rated current:
- 125 A
- Number of poles:
- 1
- Connection type:
- FRONT
- Standards:
- 60947-2
- Rated impulse withstand voltage Uimp:
- 6 kV
- Rated operational voltage (AC):
- 230 V
- Rated Insulation Voltage:
- 800 V
- Thermal Adjustment:
- no
- Magnetic adjustment:
- no
- Adjustable or fixed:
- fixed
3 Documents
11 Logistics
Product
- Net weight of the product
- 0.4 kg
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging weight
- 0.5 kg
- Transport packaging volume
- 0.748 dm³
- Transport packaging quantity
- 1 pcs
- Customs tariff
- 85362010
- Transport Packaging Dimensions Height
- 110 mm
- Transport Packaging Dimensions Width
- 40 mm
- Transport Packaging Dimensions Depth
- 170 mm
- EAN code for a transport packaging
- 3838895409434
- Pallet quantity
- 1,336 pcs
10 ETIM
- Rated voltage(Max)
- 230 V
- Complete device with protection unit
- Yes
- Rated permanent current Iu
- 125 A
- Degree of protection (IP)
- IP20
- Type of control element
- Toggle
- Position of connection for main current circuit
- Front side
- Type of electrical connection of main circuit
- Screw connection
- Number of poles
- 1
- Rated voltage(Min)
- 230 V
- Device construction
- Complete device in housing
