Switch disconnectors 125-1600A - Products & Solutions

ED2 125/3

Class name: Switch disconnector
Rated current: 125 A
Number of poles: 3
Connection type: front connection
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 3.6 kA
Rated short-time withstand current Icw at 0,3s: 2 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 125A
Short circuit capacity: 3.6 kA

ED2 160/3

Class name: Switch disconnector
Rated current: 160 A
Number of poles: 3
Connection type: front connection
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 6 kA
Rated short-time withstand current Icw at 0,3s: 3 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 160A
Short circuit capacity: 6 kA

ED2 250/3

Class name: Switch disconnector
Rated current: 250 A
Number of poles: 3
Connection type: front connection
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 6 kA
Rated short-time withstand current Icw at 0,3s: 3 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 250A
Short circuit capacity: 6 kA

ED2 400/3

Class name: Switch disconnector
Rated current: 400 A
Number of poles: 3
Connection type: front connection
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 9 kA
Rated short-time withstand current Icw at 0,3s: 5 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 630A
Short circuit capacity: 9 kA

ED2 630/3

Class name: Switch disconnector
Rated current: 630 A
Number of poles: 3
Connection type: front connection
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 9 kA
Rated short-time withstand current Icw at 0,3s: 5 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 630A
Short circuit capacity: 9 kA

ED2 800/3

Class name: Switch disconnector
Rated current: 800 A
Number of poles: 3
Connection type: front connection
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 17 kA
Rated short-time withstand current Icw at 0,3s: 10 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 1000A
Short circuit capacity: 17 kA

ED2 1000/3

Class name: Switch disconnector
Rated current: 1,000 A
Number of poles: 3
Connection type: front connection
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 17 kA
Rated short-time withstand current Icw at 0,3s: 10 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 1000A
Short circuit capacity: 17 kA
Catalogue Group: ED2

ED2 1250/3

Class name: Switch disconnector
Rated current: 1,250 A
Number of poles: 3
Connection type: extension bars
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 32 kA
Rated short-time withstand current Icw at 0,3s: 15 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 1250A
Short circuit capacity: 32 kA

ED2 1250/3 PI 3C

Class name: Switch disconnector
Rated current: 1,250 A
Number of poles: 3
Connection type: extension bars
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 32 kA
Rated short-time withstand current Icw at 0,3s: 15 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Short circuit capacity: kA

ED2 1600/3 FC

Class name: Switch disconnector
Rated current: 1,600 A
Number of poles: 3
Connection type: extension bars
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 45 kA
Rated short-time withstand current Icw at 0,3s: 20 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 1600A
Short circuit capacity: 45 kA

ED2 125/4

Class name: Switch disconnector
Rated current: 125 A
Number of poles: 4
Connection type: front connection
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 3.6 kA
Rated short-time withstand current Icw at 0,3s: 2 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 125A
Short circuit capacity: 3.6 kA

ED2 160/4

Class name: Switch disconnector
Rated current: 160 A
Number of poles: 4
Connection type: front connection
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 6 kA
Rated short-time withstand current Icw at 0,3s: 3 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 160A
Short circuit capacity: 6 kA

ED2 250/4

Class name: Switch disconnector
Rated current: 250 A
Number of poles: 4
Connection type: front connection
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 6 kA
Rated short-time withstand current Icw at 0,3s: 3 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 250A
Short circuit capacity: 6 kA

ED2 400/4

Class name: Switch disconnector
Rated current: 400 A
Number of poles: 4
Connection type: front connection
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 9 kA
Rated short-time withstand current Icw at 0,3s: 5 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 630A
Short circuit capacity: 9 kA

ED2 630/4

Class name: Switch disconnector
Rated current: 630 A
Number of poles: 4
Connection type: front connection
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 9 kA
Rated short-time withstand current Icw at 0,3s: 5 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 630A
Short circuit capacity: 9 kA

ED2 800/4

Class name: Switch disconnector
Rated current: 800 A
Number of poles: 4
Connection type: front connection
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 17 kA
Rated short-time withstand current Icw at 0,3s: 10 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 1000A
Short circuit capacity: 17 kA

ED2 1000/4

Class name: Switch disconnector
Rated current: 1,000 A
Number of poles: 4
Connection type: front connection
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 17 kA
Rated short-time withstand current Icw at 0,3s: 10 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 1000A
Short circuit capacity: 17 kA
Catalogue Group: ED2

ED2 1250/4

Class name: Switch disconnector
Rated current: 1,250 A
Number of poles: 4
Connection type: extension bars
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 32 kA
Rated short-time withstand current Icw at 0,3s: 15 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 1250A
Short circuit capacity: 32 kA

ED2 1600/4 FC

Class name: Switch disconnector
Rated current: 1,600 A
Number of poles: 4
Connection type: extension bars
Standards: IEC 60947-3
Rated impulse withstand voltage Uimp: 8 kV
Utilization category: AC-23A, DC-22A
Rated short-circuit making capacity Icm: 45 kA
Rated short-time withstand current Icw at 0,3s: 20 kA
Rated operational voltage (AC): 690 V
Rated operational voltage (DC): 250 V
Rated Insulation Voltage: 800 V
Function: Low voltage switch disconnector
Frame Size: 1600A
Short circuit capacity: 45 kA
