004656858
LPC-DW 7.5 kVAr, 440V, 50HZ Capacitor
- ETI Code:
- 004656858
- Rated DC voltage:
- 440 V
- Catalogue Group:
- LPC-DW
- Reactive power:
- 7.5 kVAr
- Rated AC voltage:
- 440 V
- Rated capacitance:
- 3x41.1
- Rated current:
- 9.84 A
- Connection type:
- Screw terminal
- Type description:
- Dry
14 Logistics
Product
- Net depth
- 116.99 mm
- Net weight of the product
- 1.1 kg
- Net width
- 115.8 mm
- Net height
- 270.2 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging weight
- 1.2 kg
- Transport packaging volume
- 1.728 dm³
- Transport packaging quantity
- 1 pcs
- Customs tariff
- 85321000
- Transport Packaging Dimensions Height
- 270 mm
- Transport Packaging Dimensions Width
- 80 mm
- Transport Packaging Dimensions Depth
- 80 mm
- EAN code for a transport packaging
- 3838895822653
- Pallet quantity
- 581 pcs
