002440120 Obsolete

* ETITEC B 150/12,5 F 1+0 Surge arrester

ETI Code:: 002440120
Function:: SPD
Surge arrester type:: T1, T2
Uc Continous Operating Voltage AC:: 150 V
Iimp(10/350) Impulse Current:: 12.5 kA
Nominal Discharge Current (8/20 μs) In:: 25 kA
Current type:: AC
Up - Voltage Protection Level:: 1 kV
Remote signalisation:: No
Leakage Current:: Yes
Network system:: TN
Number of modules:: 1
Installation:: Home and residental building protection
Built-in depth:: 68 mm
IP rating:: IP20
Applied Technology:: MOV
Catalogue Group:: ETITEC B F

Accessories

Product

Net weight of the product: 124 g
Stock unit of measure: pcs

Basic Packaging

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895542223
Basic packaging weight: 0.12 kg
Basic packaging volume: 0.2 dm³

Transport Packaging

Transport packaging quantity: 12 pcs
EAN code for a transport packaging: 3838895542230
Transport packaging weight: 1.44 kg
Transport packaging volume: 2.4 dm³
Pallet quantity: 6,672 pcs
Customs tariff: 85363090

System configuration TN-C: Yes
Max. conductor cross section flexible (fine-strand): 25 mm²
Max. conductor cross section solid (solid, stranded): 35 mm²
Test class: Type 1 + 2
Mounting method: DIN rail (top hat rail) 35 mm
Lightning impulse current (10/350 µs): 12.5 kA
System configuration TN-S: Yes
Voltage protection level: 1 kV
System configuration TN: Yes
Number of poles: 1
Signalling at the device: Optical
Max. continuous voltage AC: 150 V

ETIM Classification – Version 9.0
