002440151 Obsolete

* ETITEC B 275/12,5 F 4+0 Surge arrester

ETI Code:: 002440151
Function:: SPD
Surge arrester type:: T1, T2
Uc Continous Operating Voltage AC:: 275 V
Iimp(10/350) Impulse Current:: 12.5 kA
Nominal Discharge Current (8/20 μs) In:: 25 kA
Current type:: AC
Rated AC voltage:: 230 V
Up - Voltage Protection Level:: 1.6 kV
Remote signalisation:: No
Leakage Current:: Yes
Network system:: TN-S
Number of modules:: 4
Installation:: Home and residental building protection
Built-in depth:: 58 mm
IP rating:: IP20
Applied Technology:: MOV
Catalogue Group:: ETITEC B F

Accessories

Product

Net weight of the product: 0.6 kg
Stock unit of measure: pcs

Basic Packaging

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895542605
Basic packaging weight: 0.6 kg
Basic packaging volume: 0.65 dm³

Transport Packaging

Transport packaging quantity: 3 pcs
EAN code for a transport packaging: 3838895542612
Transport packaging weight: 1.8 kg
Transport packaging volume: 1.95 dm³
Pallet quantity: 1,332 pcs
Customs tariff: 85363090

Max. conductor cross section flexible (fine-strand): 25 mm²
Nominal voltage AC: 230 V
Max. conductor cross section solid (solid, stranded): 35 mm²
Test class: Type 1 + 2
Degree of protection (IP): IP20
Mounting method: DIN rail (top hat rail) 35 mm
Construction size: 4 modular spacing
Lightning impulse current (10/350 µs): 12.5 kA
System configuration TN-S: Yes
Voltage protection level: 1.6 kV
Number of poles: 4
Signalling at the device: Optical
Max. continuous voltage AC: 275 V

ETIM Classification – Version 9.0
