004661465
LBS 800 4P Switch disconnector
- ETI Code:
- 004661465
- Rated current:
- 800 A
- Type of Installation:
- Base plate mounting
- Number of poles:
- 4
- Thermal current Ith:
- 800 A
- Rated operational current Ie AC-21 A/B at 415V:
- 800 A
- Rated Insulation Voltage:
- 1,000 V
- Max. rated operational voltage (AC):
- 415 V
- Catalogue Group:
- Load Break Switch LBS
14 Logistics
Product
- Net weight of the product
- 11.753 kg
- Net width
- 360 mm
- Net height
- 370 mm
- Net depth
- 166 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838895718987
- Transport packaging weight
- 11.753 kg
- Transport Packaging Dimensions Height
- 294 mm
- Transport Packaging Dimensions Width
- 542 mm
- Transport Packaging Dimensions Depth
- 423 mm
- Transport packaging volume
- 67.404 dm³
- Pallet quantity
- 15 pcs
- Customs tariff
- 85365080
7 ETIM
- Version as maintenance-/service switch
- Yes
- Suitable for floor mounting
- Yes
- Rated permanent current Iu
- 800 A
- Number of poles
- 4
- Device construction
- Built-in device fixed built-in technique
- Rated operation power at AC-23, 400 V
- 450 kW
- Version as main switch
- Yes
ETIM Classification – Version 9.0
1 Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
19 Tags
004661465Switch disconnectorLBS 800 4PETISWITCHLoad Break SwitchLBSLBS body (no handle included) 3/4 POLESLBS body(no handle included) 3/4 POLES4PInternationalSwitches for panel mounting ETISWITCHLoad break switch LBSRated operational current Ie AC-21 A/B at 415V: 800 A/800 AMax. rated operational voltage (AC): 415 VThermal current Ith: 800 ANumber of poles: 4Rated Insulation Voltage: 1000 VCatalogue Group: Load Break Switch LBSSwitch disconnector TOWAR Number of poles: 4 Thermal current Ith: 800 A Rated operational current Ie AC-21 A/B at 415V: 800 A/800 A Catalogue Group: Load Break Switch LBS
