004661917
LBSCD 400 4P Switch disconnector
- ETI Code:
- 004661917
- Type of Installation:
- Base plate mounting
- Number of poles:
- 4
- Thermal current Ith:
- 400 A
- Rated operational current Ie AC-21 A/B at 415V:
- 400 A
- Rated Insulation Voltage:
- 800 V
- Max. rated operational voltage (AC):
- 690 V
14 Logistics
Product
- Net weight of the product
- 2.28 kg
- Net width
- 230 mm
- Net height
- 160 mm
- Net depth
- 99.6 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838895875802
- Transport packaging weight
- 2.28 kg
- Transport Packaging Dimensions Height
- 300 mm
- Transport Packaging Dimensions Width
- 320 mm
- Transport Packaging Dimensions Depth
- 155 mm
- Transport packaging volume
- 14.88 dm³
- Pallet quantity
- 67 pcs
- Customs tariff
- 85365080
1 Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
18 Tags
004661917Switch disconnectorLBSCD 400 4PETISWITCHLoad Break SwitchLBSLBS body (no handle included) 3/4 POLESLBS body(no handle included) 3/4 POLES4PInternationalSwitches for panel mounting ETISWITCHLoad break switch LBSRated operational current Ie AC-21 A/B at 415V: 400 A/400 AMax. rated operational voltage (AC): 690 VThermal current Ith: 400 ANumber of poles: 4Rated Insulation Voltage: 800 VSwitch disconnector Number of poles: 4 Thermal current Ith: 400 A Rated operational current Ie AC-21 A/B at 415V: 400 A/400 A
