Fuse link CH10x38 aR 12A/600V 002625008

Specifications

ETI Code:
002625008
Description:
CH10x38 aR 12A/600V
Class name:
Fuse link
Type:
CH
Size:
CH10
Rated current (A):
12
Rated AC voltage (V):
600
Characteristics:
aR
Breaking capacity AC (kA):
200
Breaking capacity DC (kA):
50
Application:
For protection of semiconductor devices
Dimensions:
10x38
Power dissipation (W):
3
Operating joule integral (A2s):
120
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
Net weight of the product
0.026 kg
Customs tariff
85361050

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895356189
Basic packaging weight
0.1 kg
Basic packaging volume
0.04

Transport packaging

Transport packaging quantity
10
EAN code for a transport packaging
3838895356189
Transport packaging weight
0.1 kg
Transport packaging volume
0.04
Pallet quantity
60000
Pallet volume
240
Classification
EC002704
Class name
Cylindrical fuse
Breaking capacity
200kA
Nominal current
12A
Size
10x38 mm
Utilization category
Other
ETIM Classification – Version 7.0

Images & Diagrams

002625008Fuse link, CH10x38 aR 12A/600VUltra QuickSystem CaR CharacteristicaR CharacteristicCH10CH10Fuse links for semi conductor protection ULTRA QUICKFuse links ULTRA QUICKCH10X38 AR 12A/6Rated current 12AType CHSize CH10Product group Semiconductor ProtectionCharacteristics aRRated AC voltage 600VDimensions 10x38Breaking capacity AC 200kABreaking capacity DC 50kAPower dissipation 3WCatalogue Group Semiconductor ProtectionStandards IEC 60269-4Operating joule integral 120A2sApplication For protection of semiconductor devicesFuse link CH10x38 CH CH10 12A 600V aR
