Fuse link CH10x38 gR 2A/700V AC/DC 002625017

Specifications

ETI Code:
002625017
Description:
CH10x38 gR 2A/700V AC/DC
Class name:
Fuse link
efuse:
1
Designed for:
Protection of PV installations
L/R (ms):
2
Product group:
Special purpose fuses
Product subgroup:
PV
Type:
CH
Size:
CH10
Rated current (A):
2
Rated AC voltage (V):
700
Rated DC voltage (V):
700
Characteristics:
gR
Breaking capacity AC (kA):
50
Breaking capacity DC (kA):
8
Application:
For protection of semiconductor devices
Dimensions:
10x38
Power dissipation (0,7x In) (W):
0,44
Power dissipation (W):
1,1
Prearcing joule integral (A2s):
1,2
Operating joule integral (A2s):
1,41
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838400052209
Net weight of the product
8.3  g
Customs tariff
85361010
logis_net_width
10  mm
logis_net_height
38  mm
logis_net_depth
10  mm

Level 1 Packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895604099
Basic packaging weight
0.08  kg

Level 2 Packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895604105
Transport packaging weight
4.1  kg
Pallet quantity
85000
Classification
EC002704
Class name
Cylindrical fuse
Rated current
2
Max. rated operation voltage Ue AC
700
Construction size
CH10
Rated voltage DC
700
Application
For protection of semiconductor devices
Size
10x38 mm
Rated voltage
Other
Utilization category
Other
Nominal current
2A
Breaking capacity
50kA
ETIM Classification – Version 7.0
