Fuse link CH10x85 gR 10A/1200V DC 002625224

Specifications

ETI Code:
002625224
Description:
CH10x85 gR 10A/1200V DC
Class name:
Fuse link
Type:
CH
Size:
CH10
Rated current (A):
10
Rated DC voltage (V):
1200
Characteristics:
gR
Breaking capacity DC (kA):
30
Application:
For protection of semiconductor devices
Dimensions:
10x85
Power dissipation (0,7xIn) (W):
1,63
Power dissipation (W):
4,2
Prearcing joule integral (A2s):
53
Operating joule integral (A2s):
91
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838895611646
Net weight of the product
0.162 kg
Customs tariff
85351000

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895611646
Basic packaging weight
0.162 kg
Basic packaging volume
0.107

Transport packaging

Transport packaging quantity
210
EAN code for a transport packaging
3838895611653
Transport packaging weight
3.7 kg
Transport packaging volume
3.386
Pallet quantity
35700
Pallet volume
575.62
Classification
EC002704
Class name
Cylindrical fuse
Application
For protection of semiconductor devices
Construction size
CH10
Nominal current
10A
Rated current
10
Rated voltage
Other
Rated voltage DC
1200
Size
Other
Utilization category
Other
ETIM Classification – Version 7.0
