Fuse link CH10x85 gR 20A/1200V DC 002625227

Specifications

ETI Code:
002625227
Description:
CH10x85 gR 20A/1200V DC
Class name:
Fuse link
efuse:
1
Designed for:
Protection of PV installations
Product subgroup:
PV
Product group:
Special purpose fuses
L/R (ms):
2
Type:
CH
Size:
10x85
Rated current (A):
20
Rated DC voltage (V):
1200
Characteristics:
gR
Breaking capacity DC (kA):
30
Application:
For protection of semiconductor devices
Power dissipation (0,7x In) (W):
1,68
Power dissipation (W):
3,85
Prearcing joule integral (A2s):
212
Operating joule integral (A2s):
314
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838400052636
Net weight of the product
16.1  g
Customs tariff
85351000
logis_net_width
10  mm
logis_net_height
85  mm
logis_net_depth
10  mm

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895611707
Basic packaging weight
0.162  kg

Transport packaging

Transport packaging quantity
210
EAN code for a transport packaging
3838895611714
Transport packaging weight
3.7  kg
Pallet quantity
35700
Classification
EC002704
Class name
Cylindrical fuse
Construction size
CH10
Rated voltage DC
1200
Application
For protection of semiconductor devices
Rated current
20
Size
Other
Rated voltage
Other
Utilization category
Other
Nominal current
20A
ETIM Classification – Version 7.0
