Fuse link CH10x85SU gR 2A/1200V DC 002625230

Specifications

ETI Code:
002625230
Description:
CH10x85SU gR 2A/1200V DC
Class name:
Fuse link
Type:
CH SU
Size:
CH10
Rated current (A):
2
Rated DC voltage (V):
1200
Characteristics:
gR
Breaking capacity DC (kA):
30
Application:
For protection of semiconductor devices
Dimensions:
10x85
Power dissipation (0,7xIn) (W):
1,13
Power dissipation (W):
2,74
Prearcing joule integral (A2s):
1,6
Operating joule integral (A2s):
1,7
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838895611424
Net weight of the product
0.195 kg
Customs tariff
85351000

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895611424
Basic packaging weight
0.195 kg
Basic packaging volume
0.153

Transport packaging

Transport packaging quantity
160
EAN code for a transport packaging
3838895611431
Transport packaging weight
3.2 kg
Transport packaging volume
3.386
Pallet quantity
27200
Pallet volume
575.62
Classification
EC002704
Class name
Cylindrical fuse
Application
For protection of semiconductor devices
Construction size
CH10
Nominal current
2A
Nominal rated current
2
Rated voltage
Other
Rated voltage at DC
1200
Size
Other
Utilization category
Other
ETIM Classification – Version 7.0
