Fuse link CH14x51 aM 16A/690V 002631009

Specifications

ETI Code:
002631009
Description:
CH14x51 aM 16A/690V
Class name:
Fuse link
Type:
CH
Size:
CH14
Rated current (A):
16
Rated AC voltage (V):
690
Characteristics:
aM
Breaking capacity AC (kA):
80
Application:
For relays, contactors and motors protection in case of short-circuit
Dimensions:
14x51
Power dissipation (W):
1,2
Standards:
IEC 60269-1, IEC 60269-2

Documents

Product

EAN code for a single product
3838895906612
Net weight of the product
18.75 g
Customs tariff
85361050

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895169703
Basic packaging weight
0.186 kg
Basic packaging volume
0.126

Transport packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895169710
Transport packaging weight
9.8 kg
Transport packaging volume
6.4
Pallet quantity
85000
Pallet volume
1088
Classification
EC002704
Class name
Cylindrical fuse
Breaking capacity
80kA
Nominal current
16A
Size
14x51 mm
ETIM Classification – Version 7.0
