Fuse link CH14x51 aR 32A/690V 002635015

Specifications

ETI Code:
002635015
Description:
CH14x51 aR 32A/690V
Class name:
Fuse link
efuse:
1
Product group:
Semiconductor Protection
Type:
CH
Size:
CH14
Rated current (A):
32
Rated AC voltage (V):
690
Characteristics:
aR
Breaking capacity AC (kA):
200
Breaking capacity DC (kA):
50
Application:
For protection of semiconductor devices
Dimensions:
14x51
Power dissipation (W):
7,6
Operating joule integral (A2s):
600
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838895362555
Net weight of the product
0.039  kg
Customs tariff
85361050
logis_net_width
14  mm
logis_net_height
51  mm
logis_net_depth
14  mm

Level 1 Packaging

EAN code for a basic packaging


Level 2 Packaging

Transport packaging quantity
10
EAN code for a transport packaging
3838895356288
Transport packaging weight
0.22  kg
Pallet quantity
31570
Classification
EC002704
Class name
Cylindrical fuse
Rated current
32
Max. rated operation voltage Ue AC
690
Application
For protection of semiconductor devices
Construction size
CH14
Size
14x51 mm
Utilization category
Other
Nominal current
32A
Breaking capacity
200kA
ETIM Classification – Version 7.0
