002421422 Obsolete

Image of *SS 225 2p 25A

*SS 225 2p 25A Center-off change-over switch

ETI Code:: 002421422
Application:: IEC/EN 60947-1, IEC/EN 60947-3
Catalogue Group:: Control switch
Catalogue Subgroup:: Change-over switch 1-0-2
Function:: Center-off change-over switch
Rated current:: 25 A
Rated AC voltage:: 400 V
Rated DC voltage:: 24 V
Number of poles:: 2
IP rating:: IP20
Max input cross-section:: 6 mm²
Rated Frequency:: 50/60 Hz
Standards:: IEC/EN 60947-1, IEC/EN 60947-3
Utilization category:: AC-22A

Accessories

Product

Net weight of the product: 0.107 kg
Stock unit of measure: pcs

Basic Packaging

EAN code for a basic packaging: 3838895297406
Basic packaging weight: 1.25 kg
Basic packaging volume: 1.47 dm³
Basic packaging quantity: 12 pcs

Transport Packaging

Transport packaging weight: 11.57 kg
Transport packaging volume: 17.4 dm³
Transport packaging quantity: 108 pcs
Customs tariff: 85365080
EAN code for a transport packaging: 3838895297413
Pallet quantity: 7,020 pcs

Max. rated operation voltage Ue AC: 400 V
Rated permanent current Iu: 25 A
Type of control element: Rocker lever
Degree of protection (IP), front side: IP20
Number of switch positions: 3
Number of poles: 2
Complete device in housing: Yes
With zero (off) position: Yes
Device construction: Built-in device
Width in number of modular spacings: 1

ETIM Classification – Version 9.0

002421422 Center-off change-over switch *SS 225 2p 25A EVE/ETIREL Build-in device EVESYS EVESYS Center-off change-over switch Center-off change-over switch International Automation, signaling and control devices Modular switches and indicators EVE Catalogue Subgroup: Change-over switch 1-0-2 Function: Center-off change-over switch Number of poles: 2 IP rating: IP20 Rated AC voltage: 400 V/400 V Max input cross-section: 6 mm² Standards: IEC/EN 60947-1, IEC/EN 60947-3 Utilization category: AC-22A Rated DC voltage: 24 V/24 V Rated current: 25 A/25 A Catalogue Group: Control switch Rated Frequency: 50 Hz/60 Hz Center-off change-over switch TOWAR Catalogue Group: Control switch Catalogue Subgroup: Change-over switch 1-0-2 Function: Center-off change-over switch Rated current: 25 A/25 A Rated AC voltage: 400 V/400 V Rated DC voltage: 24 V/24 V Number of poles: 2 IP rating: IP20 Max input cross-section: 6 mm² Utilization category: AC-22A
