002471818
PRI-51/5 Control relay
- ETI Code:
- 002471818
- Category:
- Current monitoring relay PRI-51
- Height:
- 90 mm
- Catalogue Group:
- Current monitoring relay
- Width:
- 18 mm
- Type description:
- Current monitoring relay PRI-51
- Catalogue Subgroup:
- PRI
- Function:
- Monitoring and Control relays
- Supply Voltage:
- 24-240 V
- Voltage type:
- AC/DC
- Number of contacts:
- 1
- Maximum load capacity at AC1:
- 2,500 VA
- Rated current:
- 8 A
- No. of CO contacts:
- 1
- DC rated control supply voltage Uc:
- 24 V
7 Documents
21 Logistics
Product
- Net depth
- 64.26 mm
- Net weight of the product
- 0.07 kg
- Net width
- 17.5 mm
- Net height
- 91.3 mm
- Stock unit of measure
- pcs
Basic Packaging
- EAN code for a basic packaging
- 3838895424017
- Basic packaging weight
- 0.06 kg
- Basic Packaging Dimensions Depth
- 70 mm
- Basic Packaging Dimensions Height
- 25 mm
- Basic packaging volume
- 0.17 dm³
- Basic Packaging Dimensions Width
- 97 mm
- Basic packaging quantity
- 1 pcs
Transport Packaging
- Transport packaging weight
- 0.7 kg
- Transport packaging volume
- 2.173 dm³
- Transport packaging quantity
- 10 pcs
- Customs tariff
- 85364900
- Transport Packaging Dimensions Height
- 102 mm
- Transport Packaging Dimensions Width
- 284 mm
- Transport Packaging Dimensions Depth
- 75 mm
- EAN code for a transport packaging
- 3838895424024
- Pallet quantity
- 4,600 pcs
14 ETIM
- Width
- 18 mm
- Supply voltage AC 50 Hz(Max)
- 240 V
- Voltage type (operating voltage)
- AC/DC
- Voltage type (supply voltage)
- AC/DC
- Current measuring range(Max)
- 5
- Single-phase under current possible
- Yes
- Rated switch current
- 8 A
- Current measuring range(Min)
- 0.5 A
- Depth
- 65 mm
- Type of electric connection
- Clip connection
- Single-phase overcurrent possible
- Yes
- Number of contacts as change-over contact
- 1
- Height
- 90 mm
- Supply voltage AC 50 Hz(Min)
- 24 V
ETIM Classification – Version 9.0
