002472250
HRNF-200 Control relay
- ETI Code:
- 002472250
- Function:
- Monitoring and Control relays
- Supply Voltage:
- 110-230 V
- Type of Control:
- voltage imbalance, phase failure, frequency, phase and neutral failure
- Number of contacts:
- 3
- Voltage type:
- AC/DC
- Maximum load capacity at AC1:
- 1,250 VA
- Rated current:
- 5 A
- Type of contacts:
- 1xCO
- No. of inputs:
- 5
- DC rated control supply voltage Uc:
- 24-48 V
7 Documents
21 Logistics
Product
- Net weight of the product
- 0.255 kg
- Net width
- 106 mm
- Net height
- 92 mm
- Net depth
- 62 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 1 pcs
- EAN code for a basic packaging
- 3838400181466
- Basic packaging weight
- 0.34 kg
- Basic Packaging Dimensions Height
- 100 mm
- Basic Packaging Dimensions Width
- 120 mm
- Basic Packaging Dimensions Depth
- 130 mm
- Basic packaging volume
- 1.56 dm³
Transport Packaging
- Transport packaging quantity
- 36 pcs
- EAN code for a transport packaging
- 3838400181459
- Transport packaging weight
- 12.6 kg
- Transport Packaging Dimensions Height
- 400 mm
- Transport Packaging Dimensions Width
- 380 mm
- Transport Packaging Dimensions Depth
- 600 mm
- Transport packaging volume
- 91.2 dm³
- Pallet quantity
- 576 pcs
- Customs tariff
- 85364900
32 ETIM
- Single-phase under voltage possible
- Yes
- External power supply required
- Yes
- Width
- 106 mm
- Three-phase under voltage possible
- Yes
- Single-phase hysteresis possible
- Yes
- Voltage type (operating voltage)
- AC/DC
- Voltage type (supply voltage)
- AC/DC
- Three-phase over voltage possible
- Yes
- Type of voltage measuring range
- AC
- Rated switch current
- 5 A
- Single-phase over voltage possible
- Yes
- Depth
- 91 mm
- Three-phase hysteresis possible
- Yes
- Type of electric connection
- Screw connection
- Number of contacts as change-over contact
- 3
- Height
- 62 mm
- Operating voltage AC 50 Hz(Min)
- 110 V
- Operating voltage AC 60 Hz(Min)
- 110 V
- Supply voltage AC 60 Hz(Min)
- 110 V
- Voltage measuring range 2(Min)
- 400 V
- Supply voltage DC(Min)
- 24 V
- Operating voltage DC(Min)
- 24 V
- Voltage measuring range 1(Min)
- 230 V
- Supply voltage AC 50 Hz(Min)
- 110 V
- Voltage measuring range 1(Max)
- 230 V
- Supply voltage AC 50 Hz(Max)
- 230 V
- Operating voltage AC 60 Hz(Max)
- 230 V
- Supply voltage DC(Max)
- 48 V
- Operating voltage AC 50 Hz(Max)
- 230 V
- Voltage measuring range 2(Max)
- 400 V
- Supply voltage AC 60 Hz(Max)
- 230 V
- Operating voltage DC(Max)
- 48 V
ETIM Classification – Version 9.0
