002470004
SMR-T Time relay
- ETI Code:
- 002470004
- Category:
- Multifunction relay SMR-T, SMR-H, SMR-B
- Height:
- 49 mm
- Catalogue Group:
- Time relay (Analog)
- Width:
- 49 mm
- Time range:
- 0.1 s-10 days
- Type description:
- Multifunction relay SMR-T, SMR-H, SMR-B
- Catalogue Subgroup:
- Multifunction relay
- Voltage type:
- AC
- Number of contacts:
- 1
- Function:
- Time relay
- Maximum load capacity at AC1:
- 160 VA
- Number of Functions:
- 9
- No. of NO contacts:
- 1
- Supply Voltage:
- 230 V
7 Documents
22 Logistics
Product
- Net depth
- 19.04 mm
- Net weight of the product
- 0.052 kg
- Net width
- 48.7 mm
- Net height
- 55.5 mm
- Stock unit of measure
- pcs
- EAN code for a single product
- 5904722928688
Basic Packaging
- EAN code for a basic packaging
- 8594030338346
- Basic packaging weight
- 0.05 kg
- Basic Packaging Dimensions Depth
- 39 mm
- Basic Packaging Dimensions Height
- 102 mm
- Basic packaging volume
- 0.326 dm³
- Basic Packaging Dimensions Width
- 82 mm
- Basic packaging quantity
- 1 pcs
Transport Packaging
- Transport packaging weight
- 0.723 kg
- Transport packaging volume
- 2.173 dm³
- Transport packaging quantity
- 10 pcs
- Customs tariff
- 85364900
- Transport Packaging Dimensions Height
- 102 mm
- Transport Packaging Dimensions Width
- 284 mm
- Transport Packaging Dimensions Depth
- 75 mm
- EAN code for a transport packaging
- 3838895231226
- Pallet quantity
- 4,600 pcs
12 ETIM
- Width
- 49 mm
- Function delay-on energization
- Yes
- Voltage type (operating voltage)
- AC
- Function floating contact on energization
- Yes
- Voltage type for actuating
- AC
- Number of outputs, undelayed, normally open contact
- 1
- Depth
- 13.3 mm
- With semiconductor output
- Yes
- Type of electric connection
- Soldering flag connection
- Function delay on de-energization
- Yes
- Height
- 49 mm
- Function floating contact on de-energization
- Yes
ETIM Classification – Version 9.0
1 Diagrams
1 Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
20 Tags
002470004Time relaySMR-TEVE/ETIRELControl equipmentRelaysRelaysMultifunction relayMultifunction relayInternationalAutomation, signaling and control devicesTimers and digital time relays ETIRELVoltage type: ACNumber of contacts: 1Function: Time relayMaximum load capacity at AC1: 160 VANumber of Functions: 9No. of NO contacts: 1Supply Voltage: 230 V-230 VTime relay TOWAR Voltage type: AC Number of contacts: 1 Function: Time relay Maximum load capacity at AC1: 160 VA No. of NO contacts: 1 Supply Voltage: 230 V-230 V
