002470306
SHT-14/1 Time relay - digital
- ETI Code:
- 002470306
- Type of contacts:
- 1xCO
- Voltage type:
- AC
- Number of contacts:
- 1
- No. of CO contacts:
- 1
- Function:
- TIme relay
- Maximum load capacity at AC1:
- 4,000 VA
- Supply Voltage:
- 110-230 V
- Rated current:
- 0.2 A
3 Documents
18 Logistics
Product
- Net weight of the product
- 0.064 kg
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 1 pcs
- EAN code for a basic packaging
- 3838400177797
- Basic packaging weight
- 0.097 kg
- Basic Packaging Dimensions Height
- 44 mm
- Basic Packaging Dimensions Width
- 97 mm
- Basic Packaging Dimensions Depth
- 79 mm
- Basic packaging volume
- 0.337 dm³
Transport Packaging
- Transport packaging quantity
- 10 pcs
- EAN code for a transport packaging
- 3838400177780
- Transport packaging weight
- 0.97 kg
- Transport Packaging Dimensions Height
- 102 mm
- Transport Packaging Dimensions Width
- 284 mm
- Transport Packaging Dimensions Depth
- 75 mm
- Transport packaging volume
- 2.173 dm³
- Pallet quantity
- 3,640 pcs
- Customs tariff
- 85364900
18 ETIM
- Number of contacts
- 1
- Weekly program
- Yes
- Number of channels
- 1
- Contact type
- Change-over contact (NO/NC)
- Mounting method
- DIN rail
- Automatic switching summer-/winter time
- Yes
- Accuracy per day
- 1 s
- With memory card
- Yes
- Voltage type (supply voltage)
- AC
- Autonomy in hours
- 12
- Output signal
- Other
- 24 h program
- Yes
- External programming
- Yes
- 60 min program
- Yes
- Frequency supply voltage(Min)
- 50 Hz
- Supply voltage(Min)
- 110 V
- Frequency supply voltage(Max)
- 50 Hz
- Supply voltage(Max)
- 230 V
ETIM Classification – Version 9.0
