Miniature contactors are compact, electrically controlled switches used to control and protect electric motors and other electrical loads. They are specifically designed for applications requiring smaller size and lower power consumption compared to larger contactors.Auxiliary contactors, also known as auxiliary contact blocks, are typically used in conjunction with miniature contactors to provide additional control and signaling functions within a circuit.

004646002

Image of CAEM4.31-24V- DC

CAEM4.31-24V- DC Aux.contactor

ETI Code:: 004646002
Number of poles:: 4
DC rated control supply voltage Uc:: 24 V
Rated control circuit voltage Uc (DC):: 24 V
No. of aux NO contacts:: 3
No. of aux NC contacts:: 1
Function:: Auxiliary contactors
Catalogue Group:: Accessories CEC

Product

Net weight of the product: 0.52 kg
Stock unit of measure: pcs

Transport Packaging

Transport packaging quantity: 1 pcs
EAN code for a transport packaging: 7890355149768
Transport packaging weight: 0.52 kg
Transport Packaging Dimensions Height: 122 mm
Transport Packaging Dimensions Width: 52 mm
Transport Packaging Dimensions Depth: 89 mm
Transport packaging volume: 0.565 dm³
Pallet quantity: 1,523 pcs
Customs tariff: 85364900

Rated operation current Ie, 400 V: 20 A
Voltage type for actuating: DC
Number of auxiliary contacts as normally open contact: 3
Number of auxiliary contacts as normally closed contact: 1
Rated control supply voltage DC(Min): 24 V
Rated control supply voltage DC(Max): 24 V

ETIM Classification – Version 9.0
