VL D01 16A 1p Fuse switch disconnector
- ETI Code:
- 002261003
- To use with:
- D0 fuse-links
- Catalogue Group:
- LV-fuse disconnector
- Standards:
- IEC60269-1, IEC60269-3, IEC60947-1, IEC60947-3
- Application:
- Residential and industrial installation
- Type description:
- VL D01
- Type of Installation:
- DIN rail
- Utilization category:
- AC-22A
- Size:
- D01
- Product group:
- LV-fuse disconnector
- Rated AC voltage:
- 230/400 V
- Rated DC voltage:
- 230 V
- Rated current:
- 16 A
- Number of poles:
- 1
7 Documents
22 Logistics
Product
- EAN code for a single product
- 3838400030290
- Net weight of the product
- 0.075 kg
- Net width
- 17.6 mm
- Net height
- 88 mm
- Net depth
- 74.67 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 12 pcs
- EAN code for a basic packaging
- 3838895329367
- Basic packaging weight
- 0.956 kg
- Basic Packaging Dimensions Height
- 0.077 m
- Basic Packaging Dimensions Width
- 0.09 m
- Basic Packaging Dimensions Depth
- 0.221 m
- Basic packaging volume
- 0.002 m³
Transport Packaging
- Transport packaging quantity
- 108 pcs
- EAN code for a transport packaging
- 3838895329374
- Transport packaging weight
- 8.957 kg
- Transport Packaging Dimensions Height
- 0.25 m
- Transport Packaging Dimensions Width
- 0.235 m
- Transport Packaging Dimensions Depth
- 0.295 m
- Transport packaging volume
- 0.017 m³
- Pallet quantity
- 5,616 pcs
- Customs tariff
- 85389099
4 ETIM
- Construction size
- D01
- Number of poles
- 1
- Rated voltage
- 230 V
- Rated current
- 16 A
